Face Terminals

FCV4906

Android face terminal

Explore FCV4906 for your face terminals requirements. Contact our team to confirm the configuration for your project.

01 / Explore

Designed for your workflow.

FCV4906

Android face terminal

Explore FCV4906 for your face terminals requirements. Contact our team to confirm the configuration for your project.

Explore the specifications ↓
FCV4906 product design

Develop with Android.

An Android 11 platform and 8-inch touch display support device application development. Ask our team about the Android SDK, memory configuration and interfaces for your integration.

02 / Technical details

Specifications at a glance.

FCV4906 · confirm the selected configuration with our team.
Operating systemAndroid 11
Display8-inch LCD touch screen
ProcessorQuad-core 64-bit Cortex-A55 · up to 2.0 GHz
Memory2 GB / 4 GB configurations
Storage16 GB; 32 GB / 64 GB expansion options
ConnectivityEthernet and 2.4 GHz Wi-Fi; 4G is optional
Host interfacesRS485 / RS232, USB and relay; confirm the selected interface configuration
Power input9–24 V DC · 12 V recommended

Modules, accessories and software are selected for the project. Features described as options are not included in every configuration.

03 / Installation & interfaces

Plan the installation.

  1. Wall, 86-box and pedestal installations are described for this model. Confirm the appropriate mounting assembly and cable route.
  2. Choose the network and serial-interface configuration together with the application. Confirm the power supply, relay load and required input signals before wiring.
Ask about mounting and interfaces →
04 / Documents

Manuals & specifications.

Looking for the FCV4906 manual, specification or installation drawing? Tell us which information you need and we will help identify the right document.

Request documents
All documents for FCV4906

A few things worth knowing.

What lighting conditions should we consider?

Strong backlight, direct sunlight, reflections and close-range lighting can reduce capture quality. Evaluate the terminal in its intended position and avoid pointing the camera directly toward a bright window or concentrated light source.

What kind of enrollment photograph should we use?

Use a clear, front-facing JPG without beauty filters, heavy makeup, sunglasses, a mask or other facial obstruction. File size and image dimensions can vary by software and model, so confirm the current import requirements before preparing a large enrollment set.

What should we confirm before connecting a face terminal to the network?

Confirm whether the selected configuration uses wired networking, Wi-Fi or another connection method, then collect the network and platform settings required by that system. A local network connection does not by itself prove that the device is connected to the management service, so verify both states separately.

Does registering a person automatically grant access?

Not necessarily. Identity enrollment and access permission are separate steps in many systems. Confirm that the person, credential, target device, schedule and permission group have been linked and that the authorization was delivered successfully.

Is a network connection the same as a connection to the management platform?

No. A device can have local network access without maintaining its platform or messaging connection. Check the physical network, IP settings and service connection separately, using the indicators or logs available for the selected system.

What should I share when choosing a device?

Tell us which credentials people will use, where the device will be installed, which interfaces are required and what should happen in the software workflow. A mounting drawing, host-equipment description or simple process diagram helps us identify the questions that must be confirmed before recommending a configuration.

FCV4906 / Your next step

Let’s find your configuration.

Tell us your application, installation environment and quantity. We can help with product selection, documentation and the next steps.
